STAGE A120 – SURROUND CHANNELS (5.1-CHANNEL SYSTEM)
When you use these speakers as surround-channel speakers in a 5.1-channel system, place them slightly behind
the listening position, facing each other. Ideally, they should be 5 – 6 feet (1.5m – 1.8m) above the floor. An
alternate location would be on a wall behind the listening position, facing forward. The surround speakers should
not call attention to themselves while they’re playing. Experiment with their placement until you hear a diffuse,
ambient sound accompanying the sounds that you hear from the front left, front right and center speakers.
STAGE A120 – SURROUND CHANNELS (7.1-CHANNEL SYSTEM)
When you use these speakers as surround-channel speakers in a 7.1-channel system, place the surround side
speakers directly to the sides of the listening position, at least 5 – 6 feet (1.5m – 1.8m) above the floor.
A190/A180/A170
Front Left
Speaker
A180/A170/A130/A120
Surround Left
Side Speaker
A180/A170/A130/
A120 Surround Right
Side Speaker
A125C/135C
Center Speaker
TV
A190/A180/A170
Front Right
Speaker
Surround Right
Speaker
Surround Left
Speaker
5 – 6 ft
(1.5m – 1.8m)
A190/A180/A170
Front Left
Speaker
A180/A170/ A130/A120
Surround Left Side
Speaker
A180/A170/A130/A120
Surround Left Back
Speaker
A180/A170/A130/A120
Surround Right Back
Speaker
3 – 6 ft apart
(0.9m – 1.8m)
A180/A170/A130/A120
Surround Right Side
Speaker
A125C/135C
Center Speaker
TV
A170/A130/A120
Front Right
Speaker
A120 A120
3 – 6 ft apart
(0.9m – 1.8m)
Surround Right
Back Speaker
Surround Left
Back Speaker
A120
A120
5 – 6 ft
(1.5m – 1.8m)
