INSTALLATION/CLEARANCES
Fireplace Insert Installation - Rear Flue - 6"Single Wall Pipe
Installing in front of a replace with Mantel
2.75"
(70mm)
22"
16"
Non-
Combustible
Fireplace
2.75"
Non-
Combustible
replace
Mantel: extends over
3/4" from the wall.
Trim: extends less than
3/4" from the wall.
NOTICE: Not for use in factory built replaces with hearth
weight limitations.
The Oakwood should not be installed into a factory built
replace unless the hearth area is designed to take the
maximum weight of the stove. The Oakwood, loaded with
wood weighs approximately 500 pounds (250kg).
If the replace oor can hold the 500 lb. (250 kg) Oakwood,
the stove should only be placed into the replace opening
to the point that operation of the damper bypass control and
the top load door operation is not compromised or unsafe.
(See above illustration.)
Side Wall
Combustible
Material
37"(94cm)
22" (56cm)
26"
(66cm)
16"
(40cm)
