Harman Oakwood 27
Always wear gloves when
operating the stove.
OPERATION
Do not burn wet wood!
3-90-08327R26_03/14
Cooking Grill
The Oakwood offers a unique stainless steel cooking grill
that ts in the top load opening and can easily be taken in
and out of the stove. Nothing beats the taste when cooking
over a wood re.
Note: Always wear heat resistant gloves when opening
the top loading door. The metal handle will be hot and
may cause serious harm.
Warming Shelves
Cast Iron Warming Shelves are available to accent your
Oakwood and are attached by steel braces.
Rear Heat Shield
The rear heat shield will allow you to install your Oakwood
closer to the wall. Please note there are two different shields
based on whether the unit is rear or top vented.
Bottom Heat Shield
The bottom heat shield allows the Oakwood to be installed on
a combustible oor using any non-combustible oor protector
with no specic insulating value. Note: A oor protector is
always needed.
Cozy Screen
Your Harman® Oakwood can be burned like a replace with
the optional Cozy Screen. The Cozy Screen can be used with
either the door in place or with the cast iron door removed
from the stove. When using the Cozy Screen, the damper
bypass must stay in the open position or smoke spillage will
occur. The Cozy Screen has a smoke deector on it that is
recommended to be used in all applications and must be
used on all rear vent models. Note: Depending on how well
the draft is in your installation, the smoke deector may not
be needed on the top vent models.
The Cozy Screen can be used from the start of a re or can
be used with an existing one. When starting a re with the
Cozy Screen, smoke spillage may occur until it develops a
draft strong enough to pull all smoke back into the ue.
Outside Air
The Oakwood is designed to accommodate the use of outside
air introduced directly to the stove. The opening is located at
the back of the stove. An outside air connector plate attaches
over this opening, using (2) button head bolts(already on
stove).
Check with your local building inspector to find out
requirements determining if outside air is needed when
installing the Oakwood in your area. Some signs to watch for
that indicate a possible need for outside air: poor performance
of other heaters or of the Oakwood, including smoke roll-out
and odor; the disappearance of the same symptoms when
a window is opened near the stove; and condensation on
windows in the winter. Modern homes with tight windows and
doors, vapor barriers, and particularly with exhaust systems
are the most likely to require outside air.
An outside air duct less than 5' (1525 mm) long may be 3"
[80mm] in diameter, and be made of masonry tile, 26 gauge
(0.019)galvanized steel, or other approved noncombustible
material; it should have a 1" (25 mm) clearance to
combustibles. Systems longer than 5' (1525 mm), or
containing more than two elbows, should have a 4" (100 mm)
diameter duct to provide an adequate ow of combustion air.
The air supply must originate outside the dwelling and be
screened to keep out debris, birds or animals.
DO NOT INSTALL IN A SLEEPING ROOM
3" Outside Air Duct
OPTIONS
