6
XXV Pellet Stove
I n s t a l l t h e ca st
iron flame guide
on top of the burn
pot. Make sure that
the flame guide is
fully seated on the
vertical sides of the
burn pot and that the
back of the guide
rests against the
burn pot mounting
ange.
Figure 1
The power cord is tucked inside the left rear cover panel.
To remove cord, Loosen the two 5/16" hex heads and
slide the panel outward.
Some
brands of pellet venting require a 3" clearance
to combustibles, while other brands may require
only one inch.
