10.3 Ellipse System Sub-Menu/Tab
The System menu/tab allows setting and monitoring various system elements from: system-
description to versions, system clock source, management ports, and date and time.
The System menu/tab enables access to the following sub-menus:
■ Description Menu – Sets the system description parameters, such as: name, up-time, contact,
and so on.
■ Version Information Menu – Displays version information of the unit for hardware, software,
and serial number.
■ Administration:
❑ WEB needs PW
❑ Diagnostic Report
■ Ethernet Port (Management) Menu – Manages the Ethernet port.
■ Serial Port (Management) Menu – Manages the Serial port.
■ Date Menu – Sets the unit date and time, when the system clock source is internal.
■ Front Panel Control – Controls the front panel response when not used locally.
■ BOOTP Control Menu – Manages the BOOTP control parameters.
Front Panel
To access the System menu on the front panel:
❖ Navigate Root > Configuration > Unit > System.
Web Manager
To access the System menu in the Web Manager:
❖ Select Unit > System (see Figure 10–3).
System
Description
Version Information
Administration
Ethernet Port (Management)
Serial Port (Management)
Date
Frp Control
BOOTP Control
