Harris Broadcast Flexiva FAX 5KW

Questions and Answers

M
Michael ThorntonAug 15, 2025
What to do if DS13: AC FLT on Harris Broadcast Transmitter?
- D
  dustin16Aug 15, 2025
  If the AC Mains to the Harris Broadcast Transmitter is not within the range for the service being used, or if the cabinet or wall circuit breaker has tripped, or if the fuses for the low voltage detector on each phase on the Power Supply Interface board in the rear of the power blocks are damaged, the DS13: AC FLT may occur. Verify the AC Mains, check the fuses, and ensure the circuit breaker has not tripped.
D
David SmithAug 18, 2025
What to do if MUTE LED is Red on Harris Broadcast Flexiva FAX 5KW?
- R
  rcarlsonAug 18, 2025
  If the MUTE LED is Red on the Harris Broadcast Transmitter, check the Equipment Interlock J1?9 of the USER REMOTE connector on the rear of power block 1. Also, check the MUTE line J1?7 of the USER REMOTE connector on the rear of power block 1.
F
Fernando BentonAug 21, 2025
What happens if DS15: LOAD FLT on Harris Broadcast Transmitter?
- R
  reedmichelleAug 21, 2025
  If the reject load fault has occurred on the Harris Broadcast Transmitter, the transmitter will automatically switch to Low Power Mode.
K
Kara CarlsonAug 25, 2025
What to do if DRIVE CHAIN LED is Red on Harris Broadcast Flexiva FAX 5KW Transmitter?
- V
  Victoria RobinsonAug 25, 2025
  If the DRIVE CHAIN LED is Red, check the IPA module LEDs in each power block. If both A and B sides are green, check the RF Switch Board in each power block. IPA faults could be VSWR, Over Current, Under Voltage, Overdrive, or OverTemp.
J
Julie Decker MDAug 27, 2025
What to do if DRIVE CHAIN LED is Yellow on Harris Broadcast Flexiva FAX 5KW Transmitter?
- A
  Alan LeeAug 27, 2025
  If the DRIVE CHAIN LED is Yellow on the Harris Broadcast Transmitter, check the IPA Module LEDs and the fault log for further information.
G
gabriellehuntAug 30, 2025
What to check if OUTPUT LED is Yellow on Harris Broadcast Flexiva FAX 5KW Transmitter?
- Z
  zunigakarenAug 30, 2025
  If the OUTPUT LED is Yellow on the Harris Broadcast Transmitter, check the exciter and IPA power and reflected power readings. Also, check the reject load power and temperature.
Z
zcarneySep 2, 2025
What happens if DS11: EQUIP on Harris Broadcast Flexiva FAX 5KW?
- B
  Brandon RichardsSep 2, 2025
  The Harris Broadcast Transmitter will mute until the interlock J1?9 of USER REMOTE is open, then the transmitter will return to TPO if DS11: EQUIP occurs.
C
Carolyn JonesSep 5, 2025
What to do if EXCITER LED is Yellow on Harris Broadcast Flexiva FAX 5KW Transmitter?
- K
  Keith WongSep 6, 2025
  If the EXCITER LED is Yellow on the Harris Broadcast Transmitter, check the off?air exciter RF output. The relay trips if the RF power from the exciter is too low.
C
Cynthia ThomasSep 8, 2025
What to do if POWER AMP LED is Red on Harris Broadcast Flexiva FAX 5KW?
- F
  Frederick OrozcoSep 8, 2025
  To troubleshoot a red POWER AMP LED on the Harris Broadcast Transmitter, check the fault log for further details. PA faults could be VSWR, OverCurrent, Under Voltage, Overdrive, or OverTemp.
D
Douglas DavisSep 12, 2025
What to do if POWER SUPPLY LED is Red on Harris Broadcast Transmitter?
- T
  Timothy PatelSep 12, 2025
  To troubleshoot a red POWER SUPPLY LED on the Harris Broadcast Transmitter, check the fault log and individual power supply LEDs for further details.
