RF Communications Division |
1
680 University A
venue | Rochester, NY USA 14610
www.harris.com 1-585-244-5830
C
opyright © 2004 Harris Corporation 8/04 DS-230A
Specifications for the RF-590A
Specifications are subject to change without notice.
General
Frequency Range 10 kHz to 29.999999 MHz in
1 Hz steps
Frequency Stability + 1 part in 10
6
– Standard
+
1 part in 10
8
– Optional
External Frequency
Standard
1/5/10 MHz, 0.5 VRMS
Channel Memory 100-channel capacity
Modes of Operation USB (J3E, A3J), LSB (J3E, A3J),
2-ISB (B8E, A3B) (optional),
CW (A1A, A1), AM (A3E,A3),
FM (F3E,F3)
Sensitivity For 10 dB (S+N)/N, above 50 kHz
SSB: 0.35 µv
CW: 0.15 µv (300 Hz)
AM: 1.5 µv (6 kHz)
IF Bandwidths Mode 3 dB BW (kHz)
USB 2.8
LSB 2.8
CW 0.3
CW 1.0
AM 3.2
AM 6.0
AM/FM 16
Intermodulation In Band: –50 dB or better for (2)
–7 dBm signals within the IF passband
Out of Band: –50 dB or better for (2)
0 dBm signals separated 30 kHz
or more
Reciprocal Mixing ≤ –107dBc in 3 kHz @ ≥100 kHz
separation
Image and IF Rejection –100 dB
Spurious Rejection Internal ≤ –123 dBm, external –80 dB
Maximum Signal Input Receiver pr
otected to 100 watts
available power input
AGC Range: < 3 dB audio output
variation for 1 µv to 1v input
Attack T
ime: <20 msec
Hang/Decay Times:
Short, <30 msec.;
Medium, 200
+
50 msec.;
Long, 2.5 ± .5 sec.
Data
BFO + 9.99 kHz in 10Hz steps
Hum and Noise < –50 dB
Ultimate (S+N)/N 50 dB
Audio Outputs Line Output: –16 to +10 dBm/600
ohms
Phone: +10 dBm/600 ohms
Internal Speaker: 2.0 W/8 ohms
External Speaker: 2.5 W/8 ohms
Environmental
Temperature Operating: –10˚C to +55˚C
Non-Operating: –62˚C to +71˚C
Humidity 0 to 95%
Installation
Power Supply 115/230 VAC
+
20%, 47 to 420 Hz,
Power Consumption 75 watts
Size 5.25”H x 19”W x 19.5”D max
(13.3H x 48.3W x 49.5D cm)
W
eight
40 lb (18.2 kg)
Internal Options for the RF-590A
High stability frequency standard – RF-593 Digitally-tuned preselector – RF-596A-02
2-Channel ISB – RF-595A-01
Noise blanker – RF-597A
2-Channel ISB (Delay compensated filters)
– RF-595A-02 AFSK converter – RF-599A
Syllabic squelch – RF-597A-02
assuredcommunications
™
