HART CGH002 - LED INDICATORS AND FUNCTIONS

5 – English
OPERATION
LED FUNCTIONS FOR BATTERY CHARGING
MODE LED ACTION
Solidred
PluggedintoACpowersupplyandreadytocharge.Nobatterypackin-
stalled.
Flashingred
Hot battery pack
Whenbatterypackreachescooledtemperature,chargerbeginscharge
mode.
Cold battery pack
Whenbatterypackreacheswarmedtemperature,chargerbeginscharge
mode.
Patternoftwo
quickredblinks
Battery pack or charger error
•IfthechargerindicatesError, trytorepeattheconditionsasecondtimeby
removingandreinstallingthebatterypack.IftheLEDErrorstatusrepeats
asecondtime,trychargingadifferentbattery.
•Ifadifferentbatterychargesnormally,replacethepackthatreceivedthe
Errorandrecyclethepack.(Seeyourbatterypackmanualforinstructions.)
•IfadifferentbatteryalsoindicatesError,thechargershouldbereplaced.
Flashinggreen Batteryisbeingcharged.
Solidgreen Batterychargingiscomplete.
NOTE: MAINTENANCE INFORMATION BEGINS ON PAGE 6 AFTER
FRENCH AND SPANISH LANGUAGE SECTIONS.
ILLUSTRATIONS START ON PAGE 7.
