HART HLCG01 User Manual

5 – English
OPERATION
LED FUNCTIONS FOR BATTERY CHARGING
See Figure 2, page 7.
NOTE: MAINTENANCE INFORMATION BEGINS ON PAGE 6 AFTER FRENCH
AND SPANISH LANGUAGE SECTIONS.
ILLUSTRATIONS START ON PAGE 7.
MODE LED ACTION
SolidRed
PluggedintoACpowersupplyandreadytocharge.Nobatterypack
installed.
FlashingRed
Hot battery pack
Whenbatterypackreachescooledtemperature,chargerbeginscharge
mode.
Cold battery pack
Whenbatterypackreacheswarmedtemperature,chargerbeginscharge
mode.
Deeply discharged
Chargerconditionsbatteryuntilnormalvoltageisreached,thenbegins
chargemode.
PatternofTwo
QuickRedBlinks
Batterypackorchargererror.
• Trytorepeattheconditionsasecondtimebyremovingandreinstalling
the battery pack. If the LED Error status repeats a second time, try
chargingadifferentbattery.
• Ifadifferentbatterychargesnormally,disposeofthepackthatreceived
theError(seeyourbatterypackmanualforinstructions).
• IfadifferentbatteryalsoindicatesError,thechargershouldbereplaced.
FlashingGreen Batteryisbeingcharged.
SolidGreen Batterychargingiscomplete.
