HART HLCG01 User Manual

4 – English
OPERATION
WARNING:
Donotallowfamiliaritywiththisproducttomakeyou
careless.Rememberthatacarelessfractionofasecond
issufficienttoinflictseriousinjury.
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1.Failuretodosocouldresultin
objectsbeingthrownintoyoureyesandotherpossible
seriousinjuries.
APPLICATIONS
Youmayusethisproductforthepurposelistedbelow:
ChargingHART
™
40VoltLithium-ionbatteries
NOTICE:
Chargeinawell-ventilatedarea.Donotblockcharger
vents.Keepthemcleartoallowproperventilation.
CHARGING
See Figures 1 - 2, page 7.
Battery packs are shipped in a low charge condition.
Therefore,youshouldchargethembeforefirstuse.Ifthe
chargerdoesnotchargeyourbatterypackundernormal
circumstances,returnboththebatterypackandchargerto
yournearestrepaircenterforelectricalcheck.
Chargetimevariesandisdependentupontheamphour
capacityofbatterypack.
Makesurethepowersupplyisnormalhouseholdvoltage,
120 volts, AC only, 60 Hz.
Connectthechargertoapowersupply.
Setthebatterypackdownwiththelatchfacingup.The
chargerwillslideovertheoppositeendofthebattery
pack.
Attachthechargertothebatterypackbyaligningthe
raisedribsonthebatterypackwiththegroovesinthe
charger,thenslidethechargerontothebatterypack.
The latchshouldsnapintoplace toensurecharger is
correctlyconnected.
Donotplacethechargerinanareaofextremeheator
cold.Itwillworkbestatnormalroomtemperature.
Thebatterypackwillbecomeslightlywarmtothetouch
whilecharging.Thisisnormalanddoesnotindicatea
problem.
The green LED will flash while the battery pack is
charging.
NOTE: IftheLEDturnsredandbeginsapatternoftwo
quickblinks,thechargerhasdetectedanerror.SeeLED
Functions for Battery Charging fordetails.
After charging is complete, the charger LED will stop
flashing and turn solid green until the battery pack is
removed.
Toremovethebatterypackfromthecharger,depress
thelatchandpullthechargeroffthebatterypack.
Disconnectthechargerfromthepowersupplyandstore
inadrylocation.
CHARGING A HOT BATTERY PACK
When using a tool continuously, the battery pack may
become hot. Thechargermay be placed directly onto a
hotbatterypackbutchargingwillnotbeginuntilthebattery
temperature cools to within an acceptable temperature
range.Whenthechargerisplacedonahotbatterypack
theLEDwillturnredandbeginflashing.Whenthebattery
packcools,thechargerwillautomaticallybegincharging.
CHARGING A COLD BATTERY PACK
Thechargermaybeplaceddirectlyontoacoldbatterypack
but charging will not begin until the battery temperature
warmstowithinanacceptabletemperaturerange.When
thechargerisplacedonacoldbatterypacktheLEDwill
turnredandbeginflashing.Whenthebatterypackwarms
thechargerwillautomaticallybegincharging.

HART HLCG01 Specifications

General

Brand	HART
Model	HLCG01
Category	Battery Charger
Language	English
