HART HLCG03 User Manual

5 – English
NOTE: TheLEDwillturnoff10minutesaftercharging
hasbeencompleted.
To removethebattery pack fromthe charger, depress
latchesandslidethebatterypackoutofthecharger.
CHARGING A HOT BATTERY PACK
When using a tool continuously, the battery pack may
becomehot.Ahotbatterypackmaybeplaceddirectlyonto
thechargerportbutchargingwillnotbeginuntilthebattery
temperaturecoolstowithinacceptabletemperaturerange.
OPERATION
Whenahotbatterypackisplacedonthecharger,thecharger
LED will turn red and begin flashing. When the battery
packcools,thechargerwillautomaticallybegincharging.
CHARGING A COLD BATTERY PACK
Acoldbatterypackmaybeplaceddirectlyontothecharger
portbutchargingwillnotbeginuntilthebatterytemperature
warmstowithinacceptabletemperaturerange.Whenacold
batterypackisplacedonthecharger,thechargerLEDwill
turnredandbeginflashing.Whenthebatterypackwarms
thechargerwillautomaticallybegincharging.
LED FUNCTIONS FOR BATTERY CHARGING
See Figure 1, page 7.
This product has a Three-year Limited Warranty.
For Warranty details go to www.HARTtools.com
NOTE: MAINTENANCE INFORMATION BEGINS ON PAGE 6
AFTER FRENCH AND SPANISH LANGUAGE SECTIONS.
ILLUSTRATIONS START ON PAGE 7.
MODE LED ACTION
SolidRed
PluggedintoACpowersupplyandreadytocharge.Nobatterypack
installed.Ifnobatteriesareinserted,thechargerLEDwillturnoff5min-
utesafterbeingpluggedintoACpowersupply.
FlashingRed
Hot battery pack
Whenbatterypackreachescooledtemperature,chargerbeginscharge
mode.
Cold battery pack
Whenbatterypackreacheswarmedtemperature,chargerbeginscharge
mode.
Deeply discharged
Chargerconditionsbatteryuntilnormalvoltageisreached,thenbegins
chargemode.
PatternofTwo
QuickRedBlinks
Batterypackorchargererror.
• Trytorepeattheconditionsasecondtimebyremovingandreinstalling
the battery pack. If the LED Error status repeats a second time, try
chargingadifferentbattery.
• Ifadifferentbatterychargesnormally,disposeofthepackthatreceived
theError(seeyourbatterypackmanualforinstructions).
• IfadifferentbatteryalsoindicatesError,thechargershouldbereplaced.
FlashingGreen Batteryisbeingcharged.
SolidGreen
Batterychargingiscomplete.LEDwillturnoff10minutesaftercharging
hasbeencompleted.
