OPERATION
MAINTENANCE
Thisproductcontainsnoserviceableparts.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plasticsaresusceptibletodamagefromvarioustypesof
commercialsolventsandmaybedamagedbytheiruse.Use
cleanclothstoremovedirt,dust,oil,grease,etc.
WARNING:
Donotatanytimeletbrakefluids,gasoline,petroleum-
basedproducts,penetratingoils,etc.,comeincontact
withplasticparts.Chemicalscandamage,weakenor
destroyplastic which could result in serious personal
injury.
CLEANING/REPLACING THE FILTER
See Figure 6, page 7.
Removethebatterypackandthedustbowl.
Removedustbowlfromhandvac.Pulltoremovefilter
housingandfilterfromdustbowl.
Turnfliterclockwisetoremovefromfilterhousing.Turn
clockwisetolockinplace.
Removethefilterfromfilterhousing.Shakeorlightlybrush
anydustordirtoffthefilter.
Shakeorlightlybrushanydustoffthefilterhousing.Wash
ifnecessary.
Empty the dust bowl; wash if necessary. Before
reattaching to the hand vac, make sure all pieces are
completelydry.
NOTE: Allow24hoursforpartstodrycompletely.
Whenpurchasingreplacementfilter,requestrecommended
partnumber542363001/542363002 .
NOTE: ILLUSTRATIONS START ON PAGE 7
AFTER FRENCH AND SPANISH LANGUAGE SECTIONS.
STARTING/STOPPING THE VACUUM
See Figure 2, page 7.
To start the vacuum:presstheON/OFFbutton.
To stop the vacuum:presstheON/OFFbutton.
INSTALLING ACCESSORIES
See Figure 3, page 7.
Thefollowingaccessoriesareincluded:
Item Part number
CreviceTool...........................542291001/542291002
DustBrush.............................316959001/316959002
Installonlyaccessoriesdesignedforusewiththisvacuum.
Turnoffthevacuum.
Removethebatterypack.
 Place the accessory into the port on the nose of the
vacuum.
Pushtheaccessorysecurelyintoplace.
Whennotinuse,removeandstoretheaccessory.
REMOVING/REATTACHING THE DUST BOWL
See Figures 4, page 7.
Thedustbowlshouldbechecked,emptied,andcleaned
periodicallyformaximumdustcollection.
To remove:
Removethebatterypack.
Depressthereleasebuttonlocatedontopofthehand
vac.Pullthedustbowldownandout.
To reattach:
Positionthetwosectionsasshown.Aligntheslotonthe
bottomofdustbowlwiththetabonthebottomofmotor
housing,thensnapthetwosectionstogether.
INSTALLING WALL MOUNT
See Figures 5, page 7.
Removethebatterypack.
Secure wall mount with two screws (not included) or
anchors(notincluded).
NOTE: Makesurethewallmountissecurebyfindinga
studorusingwallanchors.
Withnoseofvacuumpointingupslidethebaseonthe
wallmountasshownforstorage.
