latch
Folding
F1 F3F2
1.Assembling the chassis: see F1: Release the folding latch. Grip the handlebar
F2 with one hand. Lift the handlebar until the stroller has completely deployed and
locked.
F4 F5 F6
button
2. To assemble the wheels:
see photo, insert the stell pin of the
front wheel into the front leg until the
wheel clicks into position.
3. To detach the wheels:
see photo, press down the steel
button in side and pull out, the front
wheel can detach.
4. Fitting the safety bar: move the fabric cover aside (see F4). Fix the large oval
safety bar latch pin into the opening on the seat (the safety bar will now be at a 90
degree angle, see F5). Turn the safety bar 90 degrees. Push down on the safety
bar until a “click” can be heard (see F6).
Unfolding the stroller:
15
