Harvia M1 Instructions For Installation And Use

EN DE
3
M1
WKM11
M2
WKM2
M3
WKM3
M3 SL
WKM3SL
20 Pro
WK200
20 Duo
WK200SLUX
20 ES Pro
WK200ES
20 ES Pro S
WK200ESST
20 Boiler
WK200B
20 SL
WK200SL
20 SL Boiler
WK200BSL
Classic
140
WKC140
Classic
140 SL
WKC140SL
Classic 220
WKC220
Classic 220
Duo
WKC220LUX
Premium
WK200S
Premium VS
WK200SS
Sauna room volume (m³)
Volumen der Saunakabine (m³)
6–13 8–20 8–20 8–20 6-13 8–20 8–20
Required temperature class of
chimney
Erforderliche Temperaturklasse
des Rauchfangs
T600 T600 T600 T600 T600 T600 T600
Diameter of connection opening
(mm)
Durchmesser der Anschlussöffnung
(mm)
115 115 115 115 115 115 115
Stone quantity (max. kg)
Steinmenge (max. kg)
30 40 40 40 40
40
50 (Duo)
40
Stone size (cm)
Steingröße (cm)
Ø10–15 Ø10–15 Ø10–15 Ø10–15 Ø10–15 Ø10–15 Ø10–15
Weight (kg)
Gewicht (kg)
45
60
80 (Duo)
75
65 (B)/70 (SL)/
75 (BSL)
49
54 (SL)
65
80 (Duo)
65
70 (VS)
Width (mm)
Breite (mm)
390 430 430 430 445 475
445
590 (VS)
Depth + fire chamber extension (mm)
Tiefe + Brennkammerfortsatz (mm)
430
+210 (SL)
510
+280 (Duo)
650
510
+210 (SL/BSL)
470
+210 (SL)
515
+280 (Duo)
530
Height + adjustable legs (mm)
Höhe + verstellbare Füße (mm)
715
–
760
+ 0–30
760
+ 0–30
760
+ 0–30
770
+ 0–30
800
+ 0–30
780
+0–30
Thickness of fire chamber cover
(mm)
Stärke der Brennkammerdecke
(mm)
5 10 10 10 5 10 10
Maximum length of firewood (cm)
Maximale Länge des Brennholzes
(cm)
35 39 39 39 35 39 39
Diameter of firewood (cm)
Durchmesser des Brennholzes (cm)
8–15 8–15 8–15 8–15 8–15 8–15 8–15
Water container volume (l)
Volumen des Wasserbehälters (l)
– – 20 – –
–
30 (VS)
Table 1. Technical Data
Tabelle 1. Technische Daten
26 Pro
WK260
36 WK360
36 Duo
WK360SLUX
Classic 280
WKC280
Sauna room volume (m³)
Volumen der Saunakabine (m³)
10–26 14–36 10–26
Required temperature class of chimney
Erforderliche Temperaturklasse des Rauchfangs
T600 T600 T600
Diameter of connection opening (mm)
Durchmesser der Anschlussöffnung (mm)
115 115 115
Stone quantity (max. kg)
Steinmenge (max. kg)
50 60 60
Stone size (cm)
Steingröße (cm)
Ø10–15 Ø10–15 Ø10–15
Weight (kg)
Gewicht (kg)
65 70
80 (Duo)
70
Width (mm)
Breite (mm)
430 510 475
Depth + fire chamber extension (mm)
Tiefe + Brennkammerfortsatz (mm)
510 510
+ 280 (Duo)
515
Height + adjustable legs (mm)
Höhe + verstellbare Füße (mm)
810
+ 0–30
810
+ 0–30
850
+ 0–30
Thickness of fire chamber cover (mm)
Stärke der Brennkammerdecke (mm)
6 6 6
Maximum length of firewood (cm)
Maximale Länge des Brennholzes (cm)
39 39 39
Diameter of firewood (cm)
Durchmesser des Brennholzes (cm)
8–15 8–15 8–15
Water container volume (l)
Volumen des Wasserbehälters (l)
– – –

Harvia M1 Specifications

General

Brand	Harvia
Model	M1
Category	Wood stove
Language	English
