Harvia M3 Installation

Harvia M3 Wood Stove Installation (Chimney out the back wall) (Optional)
Remove all protective film from stainless steel parts
and the plastic wrap from stove pipe pieces before
installation.
Fasten the stove handle onto the stove door With the
screws provided.
Serenity Barrel Sauna
Assembly Instructions
tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com
Manufactured by:
Remove the screw on the back of stove and remove
the back flap.
Measure the height to the middle of the opening on
31

Harvia M3 Specifications

General

Output	13 kW
Sauna room size	6-13 m³
Dimensions (W x D x H)	390 x 430 x 710 mm
Weight	45 kg
Flue outlet diameter	115 mm
Firewood length, max	39 cm
Model	M3
Heating capacity	13 kW
Height	710 mm
Width	390 mm
Depth	430 mm
Material	Steel
Color	Black
Type	Wood-burning stove
Sauna size, max (cu ft)	459 cu ft
Weight (lbs)	99 lbs
Sauna size, min (cu ft)	212 cu ft
Dimensions (W x D x H) in inches	15.35 x 16.93 x 27.95
