Harxon HX-DU8608D User Manual

[HX-DU8608D User Manual]
9 / 10
Operation voltage
12V
Power
dissipation(Typical)
High power level
（35W）
≤110W @ DC 12V
High power level
（30W）
≤100W @ DC 12V
High power level
（20W）
≤75W @ DC 12V
Low power level (15W)
≤60W @ DC 12V
Low power level (10W)
≤45W @ DC 12V
Low power level (5W)
≤25W @ DC 12V
Standby
≤1.5W @ DC 12V
Frequency stability ≤±1.0ppm
Size
186×140×73mm
Weight About 1.5kg
Temperature(operation)
-30℃~+60℃
Temperature(storage)
-55℃~+85℃
Antenna port TNC，female
Antenna impedance
50ohm
Data interface
5Pin
Transmitter
Item Specification
RF output power
High level（35W）
45.5±0.5dBm@DC12V
High level（30W）
44.8±0.5dBm@DC12V
High level（20W）
43±1dBm@DC12V
Low level（15W）
41.8±1dBm@DC12V
Low level（10W）
40±1dBm@DC12V
Low level（5W）
37.5±1dBm@DC12V
Power stability
±1dB
Harmonics
>50dB
Receiver
Item Specification
Sensitivity
-114dBm@BER 10
-3
，9600bps
Co-channel rejection
>-12dB
Adjacent channel
selectivity
>45dB@12.5KHz
