5-PAN STACKED
Note: When stacking ovens and one of them is a smoker
oven, install the smoker oven on top.
1. See Figure 6. The top unit intended for stacking has
a mounting bracket attached to the bottom in place
of casters.
2. Remove the two outer screws from the top rear of
the bottom unit.
3. Place the top oven (at least two people required) on
top of the bottom oven and secure in place using the
original screws removed in step 2.
INSTALLATION
Figure 6. Model 5-Pan Stacking Ovens
Mounting Holes
5
Form No. CS2M-0800
