MADISON 54-IN. 6 in 1 MULTI GAME TABLE - NG5017
Parts List (Cont.)
For replacement parts please call 800-759-0977.
H7
H9 H10
T3.5 x 1/2” SCREW
H8
T3.5 x 1-1/4” SCREW
X16
X26
X4
5/32” x 1” SCREW 5/32” NUT
X26
T1
ALLEN WRENCH
X1
H1 H2 H3 H4 H5
5/16” x 1-1/8” BOLT
HARDWARE PACK - NGP7266
X8 X12 X6
X16
X24
F3.5 x 1-3/4” SCREW
T3.5 x 3/4” SCREW
T3.5 x 1-3/4” SCREWT3.5 x 1” SCREW
H6
5/16” WASHER
X24
NOTE: If you DO NOT need entire Hardware Pack,
please specifiy which part you need by description.
