Encapsulated engine
Before dismantling the exhaust system the capsule has to be dismounted:
• Remove the top cover 1 by opening the clips.
• Remove all screws 2 and remove the side cover 3.
Assembly:
• Assemble in reverse sequence.
• Before tightening the capsule all screws have to be turned in and the different covers
have to be correctly adjusted.
60
