60 Up shaft 8061-610701 87 Cable secure 8184-612101
61 M5 Nut 8NA-05N01 88 Left handle 8001-610703
62 Jointing part 8331-610701 89 Power cord 8422-601701
63 Inner jointing part 8321-610701 90 Auxiliary handle 8001-610705
64 Jointing part 8331-610702 91 Cable protector 8332-612101
65 Screw 8S JAB40-12D 92 Soft grip 8005-610701
66 Knob 8313-610702 93 Cable secure 8184-612101
67 Shaft 8061-610702 94 Screw 8SJAB 40-12D
68 Shoulder strap 8214-610701 95 Auxiliary handle 8001-610706
69 M5 Nut 8NA-05N01 96 Screw 8SJAB 40-14D
70 Fastner 8343-610701 97 Capacitor 8416-610701
71 Knob 8313-610702 98 Screw 8SJAB 40-10D
72 Sponge 8331-610705 99 Right handle 8001-610704
73 Screw 8S JAB40-18D 100 Screw 8S JAB40-14D
74 Round cover 8061-610704 101 Cable clip 8343-610702
75 Screw 8S JAB40-25D 102 Chain bar 8188-610701
76 Square cover 8061-610703 103 Saw 8129-610701
77 Konb 8313-610702 104 Bar cover 8331-610706
78 Screw 8SJAB 40-12D
79 Jointing part 8331-610704
80 Inner jointing part 8321-610702
81 Jointing part 8331-610703
82 M5 Nut 8NA-05N01
83 Round cover 8061-610703
84 Spring wire 8422-610702
85 Trigger switch 8042-612101
86 Screw 8SJAB 40-14D
SCHEMATIC DRAWING AND PARTS LIST
