SCHEMATIC DRAWING AND PARTS LIST
Pole saw schematic drawing
1 Guide bar knob 8313-612101 31 Stator 8405-610701
2 Sprocket 8061-612101 32 Tube 8061-612101
3 Washer 8208-612101 33 Ball 8203-612101
4 Washer 8CE -07B 34 Pump cap 8087-612101
5 Sprocket gear 8128-612101 35 Worm gear 8121-612101
6 Screw 8SA CD05-30D 35.1 Piston 8086-612101
7 Screw 8S FDD08-20D 36 Washer 8208-612105
8 Nut 8207-612101 37 Piston 8331-612101
9 Washer 8208-612104 38 Screw 8SJAB 40-10D
10 Cover 8347-612102 39 Oil pump 8336-612101
11 Screw 8SJAM04-10D 40 Tube 8061-612102
12 Screw 8SJAB 40-14D 41 Bearing 6000Z BC-10260 8-S T
13 Right housing 8006-612102 42 Rotor 8402-610701
14 Tank cover 8020-612101 43 Bearing 606Z BC-06170 6-S T
15 Tank strip 8343-610703 44 Left housing 8006-612101
16 Washer 8208-612103 45 Washer 8208-612106
17 Valve 8335-612101 46 Screw 8S JAB40-10D
18 Oil tank 8165-612101 47 Tube 8065-612102
19 Nut 8NG-05D 48 Tube 8065-612103
20 Motor gear 8123-612101 49 Hex key 8261-612101
21 Bearing 6900Z BC-10260 6-ST 50 Screw 8SJAB 40-14D
22 Gear 8123-612102 51 Back cover 8004-610701
23 Output shaft 8085-612101 52 Rubber pole 8087-612102
24 Bearing 608Z BC-08220 7-ST 53 Brush 8406-612101
25 Screw 8SJAB 40-14D 54 Brush holder 8409-612101
26 Gear holder 8181-612101 55 Left handle 8001-610701
27 teeth 8128-612102 56 Cable secure 8184-612101
28 Washer 8CE-06B 57 Screw 8S JAB40-14D
29 Cover 8182-612101 58 Right handle 8001-610702
30 Screw 8SJAM40-55D 59 Shaft cap 8087-610701
