Haussmann 59595063 - Parts List

12
ENGLISH
PARTS LIST
Please refer to the schematic drawing on the next page.
N
O.
DESCRIPTION N
O.
DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Cover clamp
Grinding wheel
Wheel guard
Press table
Output shaft
Woodruff key
Cross recessed head screw
Spring washer
Flat washer
Front cover
Bearing
Bearing pressing plate
Cross recessed head screw
Spacer bush
Pressing plate
Circlip
Circlip for shaft
Circlip
Tapping screw
Self-lock pin spring
Opening snap spring
Shell
Locknut
Circlip
Pinion
Bearing
Bearing cover
Sunk screw
Rotor assembly
Fan shroud
Tapping screw
Stator assembly
Bearing
Bearing holder
Cover
Brush yoke
Screw
Carbon brush
Right Brush holder cap
Tapping screw
Right handle
Tapping screw
Switch
Switch trigger
left housing
Screw
Wire clamp
Jacket
Cable Wire
Two-pin spanner wrench
Auxiliary handle
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
