Haussmann HLG033 User Manual

gb
36
PArTS LIST FOr ENgINE
N
o.
Description Qty.
1 Screw M5 x 12 1
2 Washer 1
3 Start rope reel 1
4 Rope 1
5 Recoil spring 1
6 Start cover assy. 1
7 Start handle 1
8 Ring 1
9 Screw M5 x 20 6
10 Gasket 1
11 Nut M8 1
12 Starter pawl 1
13 Start spring 1
14 Start reel housing 1
15 Stop ring 4 1
16 Oil seal 2
17 Crankcase 1
18 Bearing 6201/P5 2
19 Crank shaft 1
20 Key 3 x 5 x 13 1
21 Pin B5 x 12 2
22 Screw M5 x 12 2
23 Crankcase 1
24 Spark bracket 1
25 Pin B4 x 10 2
26 Stand-off 1
27 Screw M5 x 30 4
28 Magneto rotor 1
29 Nut M8 1
30 Ignition coil 1
31 Cord comp. 1
32 Bolt M5 x 20 2
33 Washer B 2
34 Spring 1
N
o.
Description Qty.
35 Centrifugal clutch 2
36 Washer 2
37 Screw pin 2
38 Fan cover 1
39 Bolt M5 x 20 4
40 Clip 1
41 Bearing 1
42 Ring 2
43 Piston 1
44 Wrist pin 1
45 Gasket 1
46 Piston ring 2
47 Gasket 1
48 Cylinder 1
49 Screw M5 x 18 4
50 Cowling assy. 1
51 Spark plug 1
52 Contact clip 1
53 Seal 1
54 Plug cap 1
55 Plug 1
56 Cover 1
57 Scew M5 x 20 1
58 Gasket 1
59 Mufer 1
60 Screw M5 x 12 1
61 Screw M5 x 12 1
62 Label 1
63 Bolt 2
64 Nut M5 2
65 Mufercover 1
66 Gasket 2
67 Intake manifold 1
68 Gasket 1
Please refer to the Schematic Drawing on page 38.
