Page #37 background imageLoading...
Page #37 background image
gb
v.080116 37
PArTS LIST FOr ENgINE
N
o.
Description Qty.
69 Carburetor assy. 1
69-1 Thimble tube 1
69-2 Main needle 1
69-3 Screw 1
69-4 Screw M3 x 10 2
69-5 Swivel 1
69-6 Ring 3.5 1
69-7 Turn frame 1
69-8 Airtight ring 1
69-9 Nut M6 1
69-10 Adjuster nut 1
69-11 Bracket 1
69-12 Fixed plate 1
69-13 Spring 1
69-14 Column 1
69-15 Ring 1
69-16 Outer body 1
69-17 O-ring 1
69-18 Jet 1
69-19 Pump gasket 1
69-20 Pump diaphragm 1
69-21 Mid body 1
69-22 Diaphragm gasket 1
69-23 Diaphragm 1
69-24 Fuel return 1
69-25 Priming bulb 1
N
o.
Description Qty.
69-26 Pump cover 1
69-27 Screw M3 x 22 4
70 Choke lever 1
71 Stop ring 4 1
72 Nut 4 1
73 Airlterbase 1
74 Screw M5 x 50 2
75 Starter assy. 1
76 Choke 1
77 Screw ST4.2 x 12 1
78 Airlter 1
79 Airltercover 1
80 Label 1
81 Screw 1
82 Stand plate 1
83 Rubber cover 1
84 Fuellter 1
85 Fuel line 1
86 Grommet 1
87 Tank vent 1
88 Screw M5 x 16 2
89 Fuel tank 1
90 Spacer 1
91 Gasket 1
92 Air vent 1
93 Fuel tank cap 1
94 Fuel cap assy. 1
Please refer to the Schematic Drawing on page 38.
