KNOW YOUR PRODUCT
EN
29.Slide lock
30.Trenching depth adjustment screw
31.Trenching stop
32.Trenching depth lock nut
33. 45° Bevel adjustment screw (left)
34. 45° Bevel adjustment screw (right)
35. 0° Bevel adjustment screw
36.Side support bars (x2)
37.Side support bar location holes (2 sets)
38.Side support bar stop screws (inside)
39.Stabilizer bar
40.Flange wrench
41.Side support bar locking knob (x 2)
42.Saw blade
43.Ready indicator
44.Working light
8
17
24
12
25
31
36
14
30
28
15
27
39
11
36
10
22
25A
9
44
7
13
19
23
21
B1
16
33
18
34
35
