OPERATING INSTRUCTIONS
(10) by loosening the clamp assembly lock
(11) and moving it to the other side of the table.
Make sure the clamp assembly lock is tight
before using the clamp.
10) Before turning on the saw, perform a dry run
of the cutting operation to check that there
are no problems.
11) Hold the operating handle (7) firmly and
squeeze the switch trigger (24).Allow the
blade to reach maximum speed and slowly
lowerthe bladeintoandthroughthework-
piece.
12) Release the switch trigger (24) and allow the
saw blade to stop rotating before raising the
blade out of the workpiece.Wait until the
blade stops before removing the workpiece.
Compound mitre cut
A compound mitre cut involves using a mitre
angle and a bevel angle at the same time. It is
used in making picture frames, to cut mouldings,
making boxes with sloping sides and for roof fra-
ming.Always make a test cut on a piece of scrap
wood before cutting into the good material.
Use the slide action when cutting wide work-
pieces.
1) Pull on the release knob (6) and lift the saw
arm to its full height.
2) Loosen the mitre lock (25).
3) Rotate the mitre table (21) until the pointer
aligns with the desired angle on the
mitre
scale.
4) Retighten the mitre lock (25).
WARNING.Be sure to tighten the mitre lock be-
fore making a cut.Failure to do so could result in
the table moving during the cut, causing serious
personal injury.
5) Loosen the bevel
lock (16) and pull out the 0º
bevel adjuster (18) and move the saw arm (5)
to the left or right to the desired bevel angle
(between 0º and 45º).Tighten the bevel lock
(16).
6) Place the workpiece flat on the table with
one edge securely against the fence (19).If
the board is warped, place the convex side
against the fence.If the concave side is placed
against the fence, the board could break and
jam the blade.
7) When cutting long pieces of timber, support
the opposite end of the timber with the side
bars (36), a roller stand or a work surface that
is level with the saw table.
8) Use the clamp assembly (10) to secure the
workpiece wherever possible.
9) It is possible to remove the clamp assembly
(10) b
y loosening the clamp assembly lock
(11) and moving it to the other side of the table.
Make sure the clamp assembly lock is tight
before using the clamp.
10) Before turning on the saw,perform a dry run
of the cutting operation to check that there
are no problems.
11) Hold the operating handle (7) firmly and
squeeze the switch trigger (24).Allow the
blade to reach maximum speed and slowly
lower the blade into and through the work-
piece.
12) Release the switch trigger (24) and allow the
saw blade to stop rotating before raising the
blade out of the workpiece.Wait until the
blade stops before removing the workpiece.
Adjusting the laser lines (B9)
The lower laser is factory set to emit a laser
line along the right-hand side of the blade.The
upper laser is factory set to emit a laser line to
the left-hand side of the blade.This upper laser
can be adjusted by the operator to suit blades of
different kerf widths.
To adjust the position of the upper laser, pro-
ceed as follows:
1) Remove the laser cover by pulling it towards
you.
2) Switch on the laser lights with the on/off
switch (2).
3) Using a Phillips head screwdriver (not sup-
plied), adjust the position of the line from the
upper laser by turning the laser pitch control
(4).
