• 06 •
INSTALLATION
Parts List
Connecting the Drain Hose to the Machine
WARNING: The dishwasher drain hose is an essential part of the machine, so it must be installed correctly to
drain water and perform its job effectively.
1. Connect the drain hose to the water outlet located on the back of the machine.
2. Tighten the hose collar screw with a screwdriver.
Connecting the Drain Hose to a Sewer
1. There are three options for sewer connection, A (sink), B (sink drainpipe), and C (drainage pipe). For options
B and C, it is required to drill a hole on or under the counter so that the pipe can go through the counter.
2. The drain hose must be property fitted to its containment source (such as a sink, bucket, etc.) to avoid water
leaks. Ensure that the drain hose is not kinked or impeded in any way.
Water Outlet
Hose Collar Screw
Drain Hose
Hose Collar
Inlet Hose × 1
(61 in/154 cm)
Drain Hose × 1
(61 in/154 cm)
Fruit Basket × 1 Pitcher × 1 Hose Collar × 1 Cutlery Basket × 1
To Next Page
