HSB2
Step 1 - Remove Original Antenna
Unscrew the antenna currently attached to your wireless product.
Step 2 - Connect the HSB2 Signal Booster
Use the included SMA-to-SMA cable to connect the Signal Booster.
Step 3 - Adjust Power and Plug In
Adjust the power setting on the Signal Booster and plug in the AC Adapter.
HSB2
Adjustable WiFi
Signal Booster
Network Specifications:
EEE 802.11b WLAN Standard
IEEE 802.11g WLAN Standard
Operating Frequency : 2400 - 2500 MHz
Transmit Gain: up to 27 dBm
Frequency Response: +/- 1 dB
Output Power: 100/200/500mW
Input Power: 8dBm min; 18dBm max
Receiver Gain: 10-13 dBm, 12 dBm Typical
Noise Figure: 3.5 dB typical
Connectors:
Input: Reverse SMA Jack
Antenna: Reverse SMA Jack
Connector Cables: RP-SMA
Power: External Power Adapter (12V, 1.25A)
DC Surge Protection: Available
Cable Length: 1 Meter
Certifications: FCC, CE
SYSTEM REQUIREMENTS:
802.11b or 802.11g Wireless Network
Certified 802.11b/g Wireless PCI Network Adapter
with a Removable Antenna. (HWP54G)
802.11b/g WiFi Signal Booster
(c)2005 Hawking Technologies. All Rights Reserved.
RELATED PRODUCTS:
HWP54G Hi-Speed Wireless-G PCI Card
HSB1-AP Hi-Gain WiFi Signal Booster + Wireless-G
Access Point / Bridge Kit
HAI15SC Hi-Gain 15dBi Corner Antenna
HAI6SIP Hi-Gain 6dBi Omni-Directional Antenna
FEATURES BENEFITS
Works with 802.11b & 802.11g WiFi Networks Complies with wireless standards
Adjustable Power Output Settings Boost your network range up to 600%
Plug and Play Installation Fast and easy no-hassle setup
PRODUCT VIEW:
