12•34 Wiring diagrams
Master key to wiring diagrams 16 and 17
No Description
1 Alternator
2 Battery
3 Starter motor solenoid
4 Starter motor
5 Lighting switch
6 Headlight dip switch
7 Headlight dip beam
8 Headlight main beam
9 Main beam warning light
10 Sidelight RH
11 Sidelight LH
12 Panel illumination lights
13 Number plate illumination lights
14 Stop-lights
15 Tail-lights RH
16 Stop-light switch (mechanical)
17 Fusebox
18 Interior light
19 Interior light switch (door)
20 Tail light LH
21 Horn
22 Horn push
23 Direction indicator flasher unit
24 Direction indicator switch
25 Direction indicator warning light
26 Front direction indicator light - RH
27 Front direction indicator light LH
28 Rear direction indicator light - RH
29 Rear direction indicator light LH
30 Heater switch
31 Heater motor
32 Fuel level indicator
33 Fuel level indicator tank unit
34 Windscreen wiper motor
No Description
35 Ignition/start switch
36 Ignition coil
37 Distributor
38 Oil pressure switch
39 Oil pressure warning light
40 No charge warning light
41 Headlight flash switch
42 Water temperature indicator (when fitted)
43 Water temperature transmitter (when fitted)
44 Reverse light switch
45 Reverse light
46 Radio (when fitted)
47 Voltage stabiliser
48 Line fuse
49 Automatic transmission starter inhibitor switch (when fitted)
50 Windscreen washer motor
51 Induction heater and thermostat (when fitted)
52 Carburettor dashpot heater (when fitted)
53 Tachometer (when fitted)
54 Direction indicator repeater lights (when fitted)
55 Heated rear screen switch
56 Heated rear screen
57 Combined windscreen washer and wiper switch
58 Hazard warning light
59 Hazard warning switch
60 Hazard warning flasher unit
61 Printed circuit instrument panel
62 Brake low fluid level warning light and test switch
63 Ballast resistor (cable)
64 Rear fog-guard switch
65 Rear fog-guard warning light
66 Rear fog-guard light
67 Brake fluid level sensor switch
68 Speakers (when fitted)
Cable colour code
BL Blue
BK Black
BR Brown
G Green
GR Slate
LG Light green
O Orange
P Pink
PU Purple
R Red
W White
Y Yellow
When a cable has two colour code letters, the first denotes the main colour and the second denotes the tracer colour
