Wiring diagrams 12•39
12
Key to wiring diagrams 19 to 32 inclusive
No Description No Description
1 Battery
2 Lighting
3 Dip switch
4 Dipped beam headlight
5 Main beam headlight
6 RH sidelight
7 LH sidelight
8 Number plate illumination light
9 RH tail light
10 Brake light switch
11 LH tail light
12 Horn
13 Horn switch
14 Direction indicator switch
15 RH front direction indicator light
16 LH front direction indicator light
17 Heater switch
18 Heater motor
19 Windscreen wiper motor
2û Ignition switch
21 Headlight flasher switch
22 Rear foglight switch
23 Direction indicator/hazard warning light unit
24 Automatic transmission selector indicator light
25 Windscreen washer pump
26 Heated rear window switch
27 Heated rear window element
28 Hazard warning light
29 Hazard warning light switch
3û Auxiliary cooling fan
31 Purge valve
32 Fusible links
33 LH side repeater light
34 RH side repeater light
35 Driver’s door interior light switch
36 Passenger door interior light switch
37 Dim-dip resistor
38 Auxiliary cooling fan switch
39 Alternator
40 Starter relay
41 Ignition coil
42 Crankshaft sensor
43 Throttle potentiometer
44 Coolant temperature sensor
45 Fuel pump relay
46 Main relay
47 Manifold PTC heater relay
48 Inertia switch
49 Fuel sender unit
50 Fuel pump
51 Relay module
52 Automatic transmission starter inhibitor switch
53 Accelerator pedal switch
54 Diagnostic connector
55 Stepper motor
56 Manifold PTC heater
57 Oil pressure switch
58 Brake fluid level switch
59 Ignition/charging warning light
60 Oil pressure warning light
61 Brake system warning light
62 Tachometer
63 Coolant temperature gauge
64 Fuel gauge
65 Main beam warning light
66 LH indicator warning light
67 RH indicator warning light
68 Instrument pack
69 Intake air temperature sensor
70 Interior light
71 Radio/cassette player
72 RH speaker
73 LH speaker
74 Auxiliary cooling fan relay
75 LH brake light
76 RH brake light
77 Dim-dip relay
78 Instrument panel illumination
79 Distributor
80 RH rear direction indicator light
81 LH rear direction indicator light
82 Voltage stabiliser
83 Engine management ECU
84 Lambda sensor
85 Reversing light switch
86 Rear foglight
87 Fuel injector
88 Wiper column switch
89 Starter
90 Lambda sensor relay
91 Reversing lights
92 Direction indicator relay
93 Fuse
94 Line fuse
95 Radio fuse
Cable colour code
When a cable has two colour code letters, the first denotes the main colour and the second denotes the tracer colour
BL Blue
BK Black
BR Brown
G Green
GR Slate
LG Light green
O Orange
P Pink
PU Purple
R Red
W White
Y Yellow
