SAFETY PRECAUTIONS
Decals
Decal - Control Panel
Part No: 510226 (2)
Location: Control Panel
A) Ground travel control: controls forward & reverse transmission speed
B) Bypass valve important: prevent damage - do not operate the bypass valve lever whilst the engine is
running as this will cause a rapid temperature rise in the bypass valve.
C) Hydrostatic unit bypass valve control - grip lever to close the bypass valve, grip lever to open bypass valve
release.
D) Engine stop/run switch
E) Stop engine and remove spark plug lead before performing maintenance or repair work.
F) Parking break - grip a latch lever to engage the parking brake. Unlatch and release lever to disengage the
parking brake.
G) Engine speed control - push the lever forward to increase engine speed, pull the lever back to reduce engine
speed
H) Engage cutterhead drive
I) Disengage cutterhead drive
J) WARNING: CAUTION - risk of danger/safety alert
K) Carefully read the operators manual before using the machine
L) Do not open or remove safety shields while the engine is running
M) Danger of being hit by thrown objects. Keep bystanders at a safe distance
A B C D E
H
F G
I
J K L M
