PARTS LIST - CONTENTS
1.3
1.3
STEERING & FRONT AXLE 1.4 - 1.7
ENGINE COVER & PANELS 1.8 - 1.9
CUTTERDECK 1.10 - 1.13
GRASSBAG ASSEMBLY 1.14 - 1.15
REAR AXEL & CONTROL PEDALS 1.16 - 1.19
GRASSBAG MOUNTING 1.20 - 1.21
ENGINE BATTERY & DRIVE 1.22 - 1.25
SEAT ASSEMBLY 1.26 - 1.27
ELECTRICS 1.28 - 1.29
When ordering spare parts please give the following information.
PART NUMBER, DESCRIPTION AND QUANTITY REQUIRED,
MACHINE TYPE, MODEL AND SERIAL NUMBER.
Use only Hayter spare parts, others may be dangerous and will invalidate the machine warranty.
