10
How To: Replace Rollers
Turn the cleaner upside down and remove the three
T-20 Torx screws (shown above).
Remove bottom throat
Step 29
Once the three screws are removed, lift the bottom
throat (as shown above) to remove.
Remove bottom throat
Step 30
Remove roller brush catches
Pivot each catch, that you removed the screws from to
release the roller brushes to be removed and replace.
Step 33
Turn cleaner upside down and remove the four screws
from the locations indicated above.
Remove bottom roller brushes
Step 32
To Next Page
