HDCVT TECHNOLOGY HDC-EU2100 - Rear Panel

File No.
RD-I-19-020
Version
1.0
HDC-EU2100 User Manual
Effective Date
2019-9-12
Page
6 / 8
6
5.2RearPanel

Number Name Functiondescription
1 USB2.0port ConnecttoadevicewithUSBportsuchasprinterorU
disk,etc.
2 POWERLED PowerLEDindicator.ThegreenLEDwillilluminatewhen
thereceiverisconnectedpowersupply.
3 DC12V Plug12V/1ADCpowersupplyintotheunitandco nnect
theadaptertoanACoutlet.
4 CATport TheCATportisconnectedtransmitter’sCATportbyCAT
5e/6cable.







