the top up. A successful self
test is indicated by a tone
series and flashing lights.
If the self test is not
successful, do not use
the V-Watch detector
and return it to the
factory for service.
CLEANING
To clean, wipe with a damp cloth with water.
Do not use harsh chemicals or solvents.
TECHNICAL SPECIFICATIONS
SENSITIVITY: Factory set at 50/60 Hz sensing
threshold (first beep). The detector will only detect
AC voltage. Do not use below 2400 Volts.
TYPICAL WARNING DISTANCE: 7 feet (2.13m) from
a 4kV AC conductor.
OPERATING FREQUENCY: 50Hz/60Hz
BATTERY: Three AAA alkaline batteries ANSI-24A,
IEC-LR03 or lithium ANSI 24-LF, IECFR03.
Life 2 years in storage, six months of continuous use.
BEEPER SOUND PRESSURE LEVEL: 100 db.
WEIGHT WITH BATTERY: 7.97 oz (226g)
DIMENSIONS:
Closed: 5.53” (14.0cm) x 3.54” (9.0cm) x 1.42” (3.6cm)
Open: 6.29” (15.9cm) x 3.54” (9.0cm) x 1.42” (3.6cm)
VOLTAGE RANGE: 2400VAC and above.
ENCLOSURE MATERIAL: ABS UL 94-HB.
PRINTED CIRCUIT BOARDS: FR-4 UL94V-0.
19
