3.
b.
There are two nozzles on the cleaner, one of
them opens once the other closes. Water
flows out through the open nozzle to thrust
the cleaner to move forward. Adjust the
nozzle by turning it to control the moving
route.
a.Settings of nozzle angle and moving route
Sketch: the nozzles of the cleaner are
marked with angles (0°- 40°).
Nozzle
angle
Moving
route
- 07 -
Functions and adjustment of nozzles
The cleaner moves in an approximately straight line when the nozzle angle is
0°.The cleaner moves in a more curved line at a larger angle from 0°- 40°.
Recommended three CYCLEs and nozzle settings
Setting One: default setting: 0°- 20°, for most of pools.
