Pre-Assembly
PLANNING ASSEMBLY
Compare all parts with the Package Contents list. If any part appears missing or damaged, do not use this product.
Contact Customer Service at 1-800-514-6729 or visit www.HOMEDEPOT.com/HDX.
PACKAGE CONTENTS
B
A
C
D
E
J
F
G
I
H
Part Description Quantity
A Pump 1
B Tank 1
C Hose and Shut-off Assembly 1
D Wand 1
E Cap Nut 1
F Brown Maximum Spray Volume Fan Nozzle 1
G Red High Spray Volume Fan Nozzle 1
H Yellow Low Spray Volume Fan Nozzle 1
I Adjustable Cone Nozzle 1
J Nozzle Flat Seal 1
