Hearthstone Quality Home Heating Products, Inc ® Green Mountain Insert 70 (Model 8450)
35
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your insert,
please provide the model number and the serial number. We reserve the right to change parts due to
technology upgrade or availability. Contact an authorized dealer to obtain any of these parts. Never use
substitute materials. Use of non-approved parts can result in poor performance and safety hazards.
#
Item
Description
Qty
1
AC01315
RIGID FIRESCREEN
1
2
30569
ROUND WOODEN HANDLE BLACK
2
3
2410-520
FRONT CASTING, GMI70
1
4
5450-012
HANGER, FRONT CASTING, LOWER
2
5
5450-013
HANGER, FRONT CASTING, UPPER LEFT
1
6
5450-014
HANGER, FRONT CASTING, UPPER RIGHT
1
7
2410-510
DOOR, GMI70
1
8
5450-024
HINGE WITH PIN, DOOR, UPPER
1
9
5450-026
HINGE WITH PIN, DOOR, LOWER
1
10
3030-069
GLASS, 21.25”C11.94”
1
11
94-5950510
SURROUND LOWER PANEL, 42.25” X 5.25”
1
12
94-5950110
SURROUND, STEEL, 42.25” X 31.25”
1
13
94-5950010
SURROUND EXTENSION, 2” – 4”
1
14
5021-060
GLASS CLIP
6
15
3120-021
GASKET, GLASS CLIP
6
16
4500-2105
SCREW, MACHINE, 10-24 X 3/8” UND-CUT, FLAT, PH
6
17
30094
HEX SCREW WASHER HEAD 1/4-20 X 3/4" F ZINC TYPE
10
18
30187
STAINLESS WASHER ID 17/64" X OD 1/2"
3
19
PL65233-01A
LATCH SHIM
1
20
PL65234-01A
DOOR LOCK
1
22
94-71500
HANDLE REPLACEMENT KIT
1
23
5450-020
DOOR LATCH
1
24
5450-022
ROLLER, LATCH
1
25
4300-0701
CLEVIS PIN WITH C-CLIPS
1
26
4700-0790
SPACER, DOOR LATCH, BRASS
2
27
4600-0800
WASHER FLAT, 5/16, USS, 7/8OD, BLACK
1
28
5240-138
SPRING, LATCH, WOOD STOVE
1
29
2010-254
HANDLE CRANK, CAST IRON
1
30
4500-2976
SET SCREW, 5/16-18X38”, HALF DOG
1
31
3900-179
WOOD HANDLE
1
32
4600-0400
LOCK WASHER, ¼, SPLIT
2
33
4500-1680
SCREW, MACHINE, ¼-20 X 3-1/4”, ROUND, SLOT
1
34
5450-010
DOOR HINGE, UPPER
1
35
5450-011
DOOR HINGE, LOWER
1
36
4700-0850
SPACER, HINGE
1
