Hearthstone Quality Home Heating Products, Inc ® Green Mountain Insert 70 (Model 8450)
36
#
Item
Description
Qty
37
4500-2114
MACHINE SCREW, 10-24 X 3/8”, PAN, PH, BLACK
2
38
3110-066
GASKET ROPE, 5/8”, MED DENSITY, BLACK, 7’
1
39
3110-056
GASKET ROPE, ¼”, BLACK, ADHESIVE, 6’
1
40
4500-0700
CAP SCREW, ¼-20 X 5/8”, HEX, GRADE 5, BLACK OXIDE
8
41
5400-2132
SOCKET HEAD CAP SCREWS, 10-24 X ½”, BLACK
4
42
30021
SELF TAPPING SCREW 8-32 "F" TYPE X 7/16" FLAT HEAD PHILLIPS BLACK
2
43
30764
WOODEN AIR CONTROL HANDLE
1
44
30506
SCREW PAN TORX TYPE F 1/4-20 X 1" BLACK
1
45
30206
ZINC WASHER 5/16"ID X 3/4"OD
1
46
SE65842
AIR CONTROL DAMPER ASSEMBLY
1
48
30060
THREAD-CUTTING SCREW 1/4-20 X 1/2" F HEX STEEL SLOT WASHER C102 ZINC
5
49
AC01298
5"Ø FRESH AIR INTAKE KIT OVAL
1
50
30337
SQUARE HEAD SET SCREW 1/2-13 X 1-3/4"
2
51
5450-100
LATCH AND HINGES ACCESS PANEL
2
52
30131
BLACK METAL SCREW #10 X 1/2" TYPE "A" PAN QUADREX
4
53
PL34052
LINER FIXATION BRACKET
3
54
SE65746
FAN ASSEMBLY
1
55
44092
3 POSITION ROCKER SWITCH
1
56
5450-015
SWITCH BRACKET
1
57
PL65629
JUNCTION BOX COVER
1
58
60013
POWER CORD 96" X 18-3 type SJT
1
59
PL65627
JUNCTION BOX
1
60
30413
SNAP BUSHING
1
61
PL65626
FAN WIRE GUIDE
1
62
30484
WING NUT 1/4-20
4
63
44028
CERAMIC THERMODISC F110-20F
1
64
PL65632
THERMODISC CASING
1
65
PL65746
FAN BOTTOM FIXATION PLATE
1
66
44075
TANGENTIAL BLOWER 1800 115V-60hZ-30W (S) 90 CFM
1
67
PL65748
FAN PROTECTION COVER
1
68
SE45929
INSTRUCTION MANUEL KIT MATRIX INSERT
1
70
21387
TOP AIR DEFLECTOR INSULATION
1
71
PL65505
TOP AIR DEFLECTOR PROTECTOR
1
72
PL30583
FLOOR BRICK RETAINER / SPACER
2
73
9450-00 (KIT)
SOAPSTONE: 6 1/2" X 4 1/2'' X 1 1/4''
2
74
9450-00 (KIT)
SOAPSTONE: 4 1/2'' X 9'' X 1 1/4''
14
75
9450-00 (KIT)
SOAPSTONE: 4 1/4" X 9'' X 1 1/4''
2
76
9450-00 (KIT)
SOAPSTONE: 2" X 9" 1 1/4"
4
77
PL65514
SECONDARY AIR TUBE
4
78
21389
C-CAST BAFFLE 20" X 12 1/2" X 1 1/4"
1
