6
RECESSED TO WALL INSTALLATION
STEP A. Selection a dry wall to open a hole for fireplace box. Size of hole as below chat
Figure (A)
STEP B. Fix the three wall anchors in each side of the fireplace box according to the dimensions
Showed on the drawing. Figure (B)
Framing Hole Size
Model Number
W
H
IF-1350
47.44”(120.5cm)
20.5”(52.1cm)
