Heartland WaveReader G6 Linking/Deleting Instructions

WaveReader to WaveController
Page 9 of 13
Linking/Deleting Instructions
DCN:
DOC-WaveControllerLink
Release Date
Feb 6, 2012
Proprietary Notice: This document and the information contained herein is the property of Heartland Payment Systems. This document is provided for
customer information and evaluation purposes only, and does not represent any transfer of intellectual property to the customer. No part of the document
can be reproduced or distributed to third parties without the express written permission of Heartland Payment Systems.
Step 3: Select Name to Link to Zigbee Address
Link Zigbee to Name Screen
ZB: 12AB
1)Link: 001
2)Next Name
3)Delete ZB
ZB: 12AB
1)Link: 002
2)Next Name
3)Delete ZB
ZB: 12AB
1)Link: 003
2)Next Name
3)Delete ZB
ZB: 12AB
1)Link: 004
2)Next Name
3)Delete ZB
 The top of the screen shows the Zigbee Address selected to
link to a Name
 Press the Button to scroll through the Machine Names
 The Machine Name appears next to Link:
 NOTE: For a Shared Escrow Stack Machine (2 Machines and
1 WaveReader), Link the BOTTOM Machine Name to the
Zigbee Address. Do NOT use the TOP Machine Name.
 When the correct Machine is found to match with the Zigbee
Address, Press the Button to select that Link
Step 4: Save Link
Save/Cancel Zigbee Link
Screen
12AB 001
2)Save
3)Cancel Link
 The Zigbee Address along with the Machine Name is
displayed on the top of the screen
 To Save the Link, Press the
Button
 To Cancel the Link, Press the
Button
 It will return to the Configure Zigbee
