WaveReader to WaveController
Linking/Deleting Instructions
Proprietary Notice: This document and the information contained herein is the property of Heartland Payment Systems. This document is provided for
customer information and evaluation purposes only, and does not represent any transfer of intellectual property to the customer. No part of the document
can be reproduced or distributed to third parties without the express written permission of Heartland Payment Systems.
6.0 Installation in a High-rise Location
When installing in a High-rise location where the laundry rooms are located above each other, the readers
will connect to the WaveController by hopping vertically across adjacent floors. This will only occur
when the readers are all part of the same network. While the network is under construction the various
WaveReaders will not connect through the building to the WaveController. The configuration method for
high-rise apartments is similar to that of a large room except that the operator must configure each floor
independent of the one above or below.
To configure a high-rise building perform the following steps.
Step 1
Determine the most likely configuration for the WaveController.
Ex:
Floor 3 – WaveController Location
Step 2
Relocate the WaveController to the first floor and link the WaveReaders corresponding to the first floor.
Follow Sections 3 and 4 to Link up the WaveReaders to the WaveController. Remember to SAVE the
configuration on each floor.
Step 3
Repeat the Step 2 on each floor until all of the mapped floors are saved into the WaveController.
Step 4
Locate the WaveController on the target floor (example 3rd floor)
Step 5
Bring up the location as you would a large room.
Step 6
Repeat the process for all WaveControllers in the high-rise tower.
