Tube: COMpleMents 4) 5 <a ese WS ee ee ease
Diode Complement, , .
eoeeteeseeeseeeeee
Power Supply. ...-e-.
Ce ee ee ee
Power Requirements, oeesee ee ereeeeeee
Cabinet Dimensions, . . . 22s cesccccces
Net Weight, oeoee@e¢ @
Equipment Used To Prepare Specifications, ...
Page 123
1 - OA2: Regulator,
1 - 6AU6: Isolation Amplifier,
1 - 6AV1i1: USB, CW, and LSB Carrier Gener-
ator, and Carrier Generator Cathode Fol-
lower,
1 - 6AW8: Heterodyne Oscillator and Receiver
Heterodyne Oscillator Amplifier,
1 - 6CL6: Driver,
1 - 6D10: VOX, Relay, andSide Tone Amplifier,
1 - 6EA8: Audio Preamplifier and Cathode Fol-
lower,
2 - 6EW6: LMO Mixer, Heterodyne Mixer,
1 ~ 6311: Anti-VOX Amplifier and Tone Oscil-
lator,
2 - 6146: Final Amplifiers,
1 - 6BZ6: LMO,
5 - Crystal Diodes: Balanced Modulator and
Relative power metering,
12- Silicon Diodes: Power Supply, VOX Recti-
fiers, ALC Rectifiers, and DC Blocking,
Transformer operated,
105-125 or 210-250 volts AC, 50/60 Hz,
Standby: 80 watts,
CW: 260 watts (key down).
14-7/8" wide x 6-5/8" high x 13-3/8" deep,
26-1/2 lbs,
Heath IG-72 Audio Generator,
Heath IM-11 VTVM with 309-C RF Probe,
Heath IM-21 AC VTVM,
Heath HN-31 ''Cantenna,”
Panoramic Radio Products, Inc,
"Panalyzor,'' Model SB-12A,
Measurements Corporation, Standard Signal
Generator, Model 80,
Hewlett Packard Electronic Counter,
Model 5248,
Boonton RF Voltmeter, Model 91-C and 91-CA,
Bird Thruline Wattmeter, Model 43,
TTT << o> (RSI rr
The Heath Company reserves the right to discon-
tinue instruments and to change specifications at
any time without incurring any obligation to
incorporate new features in instruments pre-
viously sold,
