- 13 -
Service Call 0844 736 9138, Technical Help (Chargeable) Call 0844 736 0053
Temperature of the water
°C
Minimum 38
Maximum 60
TIMER
Setting the time
Rotate the outside of the clock face (2)
clockwise to indicate the current time (4)
at the black arrow (5).
Setting the programme “ON and OFF”
times.
Refer to diagram.
Select the ON times by pushing the
black tappets to the outside (3).
Select the OFF times by pushing the
black tappets to the inside (4).
Position the selector switch (1) to the
timed position
.
The heating will now operate your
chosen programme.
Operate the boiler using the timer.
Set switch (1) to the central (timed)
position.
Move the selector switch (1) to the I
position and the heating will operate
continuously.
Move the selector switch (1) to the 0
position to switch the heating OFF,
noting that the DHW will still operate.
12
3
5
4
