INSTALLATION INSTRUCTIONS R−410A Split System Air Conditioner
4 421 01 1701 00
Table 1 − Accessory Usage
Accessory
REQUIRED FOR LONG LINE
APPLICATIONS* (Over 80 ft. / 24.38 m)
Required for Sea Coast Application
(within 2 miles/3.22 km)
Crankcase Heater Yes, standard on some units No
Compressor Start Assist Capacitor and Relay Yes No
Liquid Line Solenoid Valve See Long Line Applications Guideline No
Support Feet No Recommended
* For tubing line sets between 80 and 200 ft. (24.38 and 60.96 m) and/or 20 ft. (6.09 m) vertical differential, refer to Long Line Applications Guideline.
Table 2 − Refrigerant Connections and Recommended Liquid and Vapor Tube Diameters (In.)
UNIT SIZE
LIQUID
RATED VAPOR
up to 80 ft. (24.38 m)*
Connection and Tube
Diameter
Connection
Diameter
Rated Tube
Diameter
724 3/8 3/4 3/4
924 3/8 7/8 7/8
736, 936 3/8 7/8 7/8
748, 948 3/8 7/8 1−1/8
760, 960 3/8 7/8 1−1/8
* Units are rated with 25 ft. (7.6 m) of lineset. See Specification sheet for performance data when using different size and length linesets.
Notes:
1. Do not apply capillary tube or fixed orifice indoor coils to these units.
2. For Tubing Set lengths between 80 and 200 ft. (24.38 and 60.96 m) horizontal or 35 ft. (10.7 m) vertical differential 250 ft. (76.2 m) Total Equivalent Length),
refer to the Long Line Applications Guideline.
