If you have an outlet to the outside, your cooker hood can be connected as below
picture by means of an extractions duct (enamel, aluminum, flexible pipe or
inflammable material with an interior diameter of 150mm).
1. Before installation, turn the unit off and unplug it from the outlet.
2. The cooker hood should be placed at a distance of 65~75cm above the cooking
plane for best effect.
3. After deciding the cooker hood height, measure the position of the holes for
hanging hood and inside chimney bracket. Drill 4 φ8 holes, 2 for inside chimney
bracket and 2 for hanging the hood, and keep the hood level. The fixed position of
the inside chimney bracket is the highest place of chimney. See pic 2.
