HELGI HLG0314-V2.0 User Manual

SPECIFICATION
Items Specifications
Input ports 1 x HDMI
Output ports 4 x HDMI
Power indicator led
1 xLED
Signal indicator led
4xLED
HDMI Version
Compatible with DVI1.0, HDMI1.4,HDMI2.0
HDCP Version
Compatible with HDCP1.4,HDCP2.2
HDMI Resolution 480i/480p/756i/756p/720p/1080i/1080p/
4K×2K@24/25/30/60Hz
Frequency Range
25MHz~600MHz
Video form
Support 12 bit full HD video, 3D video and
4K×2K@30/60Hz ultra HD video
Input and output
TMDS signal
0.5~1.5Vp-p(TMDS)
Input and output
DDC signal
5Vp-p(TTL)
Audio
Support standard audio and DSD（Direct Stream
Digital）and HD(HBR) audio
Working temperature
0
℃～
60
℃
Power supply
DC5V/2A
Power consumption
<8W
Dimension
158mm(L)x80mm(W)x17mm(H)
Weight 196g
Color Black
Disclaimer
The product name and brand name may be registered trademark of related manufacturers.TM
and
® may be omitted on the user manual. The pictures on the user manual are just for
reference,and there may be some slight difference with the real products.We reserve the rights to
make changes without further notice to a product or system described herein to improve
reliability, function or design.
