Specifications
Hull Width
135 mm (5.3”)
Hull Length 650 mm
Mast Height 950 mm (37.4”)
Total Height 1365 mm (53.75”)
Weight 1.35 kg (47.62 oz.)
Batteries 8 AA (included)
Servos Sail winch servo and rudder servo
Instruction Manual
Quick Start Guide

Questions and Answers

Summary

Specifications

Safety Precautions and Warnings

Box Contents

Installation and Rigging Guide

Step 1: Setup Display Base

Setup the display base by inserting tubes into sockets without glue.

Step 2: Attach Keel and Ballast

Attach keel, rubber piece, and ballast using HM 5x25mm screw and 4.0mm allen key.

Step 3: Secure Keel to Hull

Secure keel and rubber piece to hull using HM 5x50mm screw and 4.0mm allen key.

Step 4: Install Rudder Assembly

Insert rudder through hull, connect to rudder arm, and tighten screw.

Step 17: Main Sail Rigging Adjustment

Adjust silicone rings on main boom for sail tension and boom center position.

Step 18: Jib Sail Rigging Adjustment

Adjust jib boom rigging for sail tension, jib angle, and boom position relative to mast.

Step 19: Jib Boom Balance Adjustment

Adjust jib boom counterweight for neutral balance and equal movement.

Pair Transmitter and Receiver

Transmitter Functions

How-to-sail Instruction
