12 HM1734-WM Strain Gage Input Module
Troubleshooting with the Indicators
Module Status:
No power applied to device.
Device operating normally.
Device needs commissioning due to configuration
missing, incomplete or incorrect.
Unrecoverable fault. May require device replacement.
Network Status:
Device is not on-line. Device has not completed
dup_MAC_id test. Device not powered. Check module
status indicator.
Device on-line and has connections to the established
state.
Device is on-line but has no connections in the
established state.
One or more I/O connections is in timed-out state.
Critical link failure – failed communications device.
Network access error and is in communication faulted
state. Device has received and accepted an Identity
Communication Faulted Request – long protocol
message.
