21 HM1734-WM Strain Gage Input Module
Data Map for HM1734-WM on Ethernet/IP
Required Controller Tags
Data Tags Name
Data
Type
HM1734WM1
DINT[9]
HM1734WM1_A[0]
DINT
CH1 Set Scale Value
HM1734WM1_A[1]
DINT
CH1 Set AutoCal Reference Weigh Actual Value
HM1734WM1_A[2]
DINT
CH1 Get Weigh Value
HM1734WM1_A[3]
DINT
CH2 Set Scale Value
HM1734WM1_A[4]
DINT
CH2 Set AutoCal Reference Weigh Actual Value
HM1734WM1_A[5]
DINT
CH2 Get Weigh Value
HM1734WM1_A[6]
DINT
CH1 Set AutoCal Enable Bit
HM1734WM1_A[7]
DINT
CH2 Set AutoCal Enable Bit
HM1734WM1_A[8]
DINT
Set Average Sample Count (0-255)
HM1734WM1b
REAL[2]
HM1734WM1_B[0]
REAL
CH1 Set mV_V
HM1734WM1_B[1]
REAL
CH2 Set mV_V
HM1734WM1_B[2]
REAL
Ch1_Autocal_mV/V
HM1734WM1_B[3]
REAL
Ch2_Autocal_mV/V
